AMD X4 5350 Athlon 5350 2.05 GHz Quad-Core Quad-Thread CPU AD5350JAH44HM Socket AM1 Sealed New and come with cooler
AMD X4 5350 Athlon 5350 2.05 GHz Quad-Core Quad-Thread CPU AD5350JAH44HM Socket AM1 Sealed New and come with cooler
Product Details
The AMD X4 Athlon 5350 is a processor designed for the entry-level desktop market, featuring low power consumption and integrated graphics cards. The following is a detailed introduction:
Core parameters: Adopting 28nm process and based on Kabini architecture. It has 4 cores and 4 threads, with a core frequency of 2.05GHz and no turbo frequency function. The first level cache is 64KB per core, the second level cache is 512KB per core, and the total second level cache is 2MB.
Slot type: When using AM1 slots, when selecting a motherboard, it is necessary to pair it with a motherboard that supports AM1 slots.
Memory support: Supports DDR3 memory, rated speed of 1600MT/s, single channel memory, does not support ECC memory.
Graphics capability: Integrated Radeon R3 128CU display core, graphics core frequency of 600MHz, supports 2 display screen outputs, can meet daily office, web browsing, and light video playback needs, and can also run some small games with low graphics performance requirements.
Power consumption and heat dissipation: The thermal design power consumption (TDP) is only 25W, with low power consumption and low requirements for heat dissipation. Usually, there is no need to equip particularly powerful heat dissipation devices, which helps to build a low-power, low-noise computer platform.
Performance and positioning: This processor is positioned at the entry-level level, mainly aimed at users who do not have high performance requirements and pay attention to power control. It is suitable for daily office scenarios, such as word processing, spreadsheet creation, etc., and can also meet simple home entertainment needs
AMD Athlon 5350 specifications
General information | |
Type |
|
Market segment |
Desktop |
Family |
|
Model number ? |
|
CPU part numbers |
|
Frequency ? |
2050 MHz |
Package |
721-pin lidded organic micro Pin Grid Array (UOF721) |
Socket |
Socket AM1 / FS1b |
Size |
1.38" x 1.38" / 3.5cm x 3.5cm |
Weight |
1oz / 29.5g |
Introduction date |
|
Architecture / Microarchitecture | |
Microarchitecture |
Jaguar |
Processor core ? |
|
Core stepping ? |
KB-A1 |
CPUID |
700F01 |
Manufacturing process |
0.028 micron |
Data width |
64 bit |
The number of CPU cores |
4 |
The number of threads |
4 |
Floating Point Unit |
Integrated, 128-bit wide |
Level 1 cache size ? |
4 x 32 KB 2-way set associative instruction caches |
Level 2 cache size ? |
2 MB 16-way set associative shared inclusive cache |
Level 3 cache size |
None |
Cache latency |
3 |
Physical memory |
16 GB |
Pipeline |
16-stage [1] |
Multiprocessing |
Uniprocessor |
Features |
|
Low power features |
|
Integrated peripherals / components | |
Integrated graphics |
GPU Type: Radeon R3 series |
Memory controller |
The number of controllers: 1 |
Other peripherals |
|
Electrical / Thermal parameters | |
V core ? |
0.5V - 1.4V |
Maximum operating temperature ? |
90°C |
Thermal Design Power ? |
25 Watt |
